USB Capture HDMI Gen 2
USB Capture HDMI Gen 2

One-channel HD capture device

Part number: 32060

SKU: 320600000

  • HDMI + embedded audio

Interface

Specifications and Features

Interface

Input Interface

  • One HDMI input+ embedded audio
  • Support input resolution up to 2048×2160 pixels

Host Interface

  • USB 3.0, compatible with USB 2.0

OS

  • Windows, Linux, Mac, Chrome OS

Capture format

  • Support capture resolutions up to 2048x2160
  • Support capture frame rates up to 120fps
  • Support 2-channel audio streams

Included Software

  • USB Capture Utility, Capture Express, etc.

Compatible Software

  • Zoom Rooms, Microsoft Teams Rooms, Skype for Business, Google Hangouts, GoToMeeting, VLC, OBS Studio, XSplit, etc.

Others

  • Auto detection of input signal format
  • Windows, Linux and Mac SDK
  • Continuously work for 24hx7
  • LED status indicator
  • 2-year warranty
  • Form factor: 92.2mm (L) x 40.2mm (W) x 12.3mm (H)
Tools

Tools
document document Download

V3.0.3.4202

History version Arrow Arrow

10.5 MB | 2018.03.16

Descriptions:
  1. Improve the end-user visual experience for display scaling. The software will scale to the right size to show the full size of user interface if the system scales up too much.
  2. Support to modify the EDID file in the USB capture device by using Utility V3 to customize the timing parameters in the HDMI tab.
  3. Support for the Chinese user interface.
Tools
document document Download

V3.0.3.4202

History version Arrow Arrow

12.4 MB | 2018.03.16

Descriptions:
  1. Support to modify the EDID file in the USB capture dongle by using Utility V3 to customize the timing parameters in the HDMI tab.
  2. Support for the Chinese user interface.
Tools
document document Download

V3.0.3.4202

History version Arrow Arrow

13.2 MB | 2018.03.16

Descriptions:
  1. Support to modify the EDID file in the USB capture dongle by using Utility V3 to customize the timing parameters in the HDMI tab.
  2. Support for the Chinese user interface.
Tools
document document Download

V3.0.3.4202

History version Arrow Arrow

17.5 MB | 2018.03.16

Descriptions:
  1. Support to modify the EDID file in the USB capture dongle by using Utility V3 to customize the timing parameters in the HDMI tab.
  2. Support for the Chinese user interface.
Documents
Documents Short FAQs about USB Capture (Plus)
English | 57.6 KB | 2021/01/19
Documents USB Capture Utility V3 User Manual
English | 2.01 M | 2017/10/13
Accessory

Included


USB 3.0 Cable

Part number: 90062

Optional

Mini Repeater 4K HDMI

Learn more
