IP to QHD HDMI device - Magewell

Pro Convert IP to HDMI

Converts up to four IP streams into one QHD HDMI signal

SKU: 644300000

Up to 4 IP streams can be decoded and output in a preset layout, including a single main window, the picture-in-picture or quad-screen mode
Connects baseband presentation or distribution equipment into IP-based media networks
Video preview, in real-time stream or MJPEG picture is available on the web GUI

Specifications and Features

Support decoding 1 stream of up to 2560x1440p60 in H.264/H.265, SpeedHQ, and MPEG2 format
Support NDI High Bandwidth, NDI HX, NDI HX2, NDI HX3, SRT, TS over RTP/UDP, RTMP, RTSP, HLS, ZIXI protocols
Support multiview layouts
- For quad-screen, support decoding 4 streams of H.264/H.265 at up to 1920x1080p60 simultaneously
- For picture-in-picture, support decoding 2 streams of up to 1920x1080p60 simultaneously, with a maximum of 1 stream in H.264/H.265, SpeedHQ, or MPEG2 format
Support decoding audio in AAC, MP3, AC3, Opus, and G.711 formats
Support NDI 6.x

Max output: 2560x1440 60fps 4:4:4 10-bit
Delivering video at the preferred video format according to the capabilities of the connected monitor
Support 48/96KHz 8-channel audio output
Support HDR10

Advanced configuration and device status through intuitive Web GUI, keyboard/mouse, or on-board controls
Register with Control Hub for remote centralized management
Support preview of output images and PTZ control
Provide HTTP APIs
LED status indicators
Form factor: 4.72 in (L) x 3.12 in (W) x 0.96 in (H) (120 mm x 79.3 mm x 24.5 mm)

Documents

User Manual for Pro Convert IP Decoder
